High printing speed 80mm kiosk thermal printer KP-80B

Category Tags , , , ,

Designed for high-speed performance, the KP-80B series 3-inch thermal printer module with automatic cutter is ideal for self-service terminals. It’s commonly used in finance, telecom, tax offices, libraries, fuel dispensers, parking systems, and queuing equipment

Additional information

Item no.

KP-80B
Dimension

112.23*103.48*175.3mm
Color

N
Payment

Paypal, Western Union, T/T
Lead Time

1-2 weeks
ASK FOR A QUOTE

Product Details:

The compact, flexible, and highly reliable kiosk printing mechanism is perfect for standalone self-service installations across Retail, Hospitality, Healthcare, and more. Operating with direct thermal technology, this series achieves print speeds up to 250 mm per second at 203 dpi resolution. Equipped with a variety of paper-saving and design features, it supports multiple mounting options, giving kiosk builders the flexibility they need. A full range of drivers and utilities are also available for seamless integration.

Key Features：

  • Multiple Interface Support
    • Equipped with USB, serial, and Ethernet ports, providing flexible connectivity for various systems.
  • Versatile Paper Compatibility
    • Supports ticket paper, label paper, and black mark paper, making it suitable for diverse printing needs.
  • User-Friendly Automatic Cutter and Paper Unloading
    • Includes an automatic cutter and paper unloading feature for convenient, user-friendly operation.
  • Optimized for Unmanned Environments
    • Designed to maximize paper usage and operate intelligently in unmanned setups.
  • Anti-Jam and Anti-Pull Features
    • Built with anti-jamming and anti-pull functions to minimize failures and ensure smooth operation.
  • Easy Paper Loading System
    • Features a simple side-cover opening for quick paper loading, along with an auto-feed option.
  • Quick Paper Jam and Cutter Reset
    • Allows fast paper jam clearance and cutter reset by simply opening the cover, ensuring seamless operation.

Product specification:

Model:KP-80B
Printing method:Thermal dot line printing
Resolution:203Dpi(8dot/mm)
Printing speed:MAX.250mm/s
Printing width:80mm
Interface:Serial,USB,Ethernet
Paper type:Thermal paper,Die-cut label paper, black mark paper
Paper width:23-82.2mm（adjustable）
Paper roll diameter:Max.120mm(Diameter above 150mm can be customized)
Paper thickness:0.053-0.2mm
Auto cutter:Full and half cuts (by command)
Reliability:TPH life 100km(12.5% printing rate)
Cutter life:More than 1 million times
Font:Chinese GBK:16×16,24×24
western languages ASCII:8×16,9×17,9×24,12×24
Barcode:1D UPC-A,UPC-E,EAN8,EAN13,code39,ITF,CODEBAR,CODE128,CODE93
2D QR code,PDF417
Memory:RAM 64K/Flash 4M
Power supply:DC 24V/2A（peak≥6）
Command:ESC/POS（Ticket）、CPCL、TSPL、JPL（Label）
Driver:Windows XP、7、8、10/ Linux/MAC OS
SDK:Windows SDK/Linux SDK/Android SDK/IOS SDK
Operating temperature:0°C-50°C
Operating humidity:20%RH-85% RH
Storage temperature:-20°C-60°C
Storage humidity:5%-90%RH
Dimension(WxDxH) With paper outlet:112.23*103.48*175.3 mm(Paper roll not included)

Applications:

1. ATM
2. Gaming/lottery machines
3. Car parking
4. Info and multimedia kiosks
5. Currency change
6. Information stands
7. Queuing machines
